Empty folder whos like file

Suite and Optimus Suite 5
#1

Hello, I have problem with render empty folders from json files.

For example I have 3 folders, which I will need display. Two of them with files and one of them empty.

This is json source file:
{id:0,item:[
{id:1, text:“FirstFolder”, item:[
{id:2, text:“FirstFile.ini”},
{id:3, text:“SecondFile.ini”}]},
{id:4, text:“SecondFolder”, item:[
{id:5, text:“FirstFile.ini”},
{id:6, text:“SecondFile.ini”}]},
{id:7, text:“ThirdFolder”, item:[]}
]
}

After generating tree, I see:

But “ThirdFolder” also folder, but looks like file. Maybe my json structure incorrect? Or something else?
Thank’s for your respond

#2

In the tree, elements are rendered as folders only if they have non-zero count of child items. Which is not in your case.

You can define images, which will be used by the item directly in json, so it will always show a folder icon, without relation to count of child items

#3

Thank you for your reply.
But I can’t find JSON specification, which will allow me make correct json file. Please, can you write some example with directly definition of icon or tell me where I can read about that?
Thank you!

#4

You mean something like this:
{id:2, img:“icon.png” ,text:“FirstFile.ini”} ?

#5

The example:

{id:2, im0:“icon.png”,im1:“icon.png”,im2:“icon.png”,text:“FirstFile.ini”}

  • im0 - the icon for a leaf node;
  • im1 - the icon for an expanded parent node;
  • im2 - the icon for a collapsed parent node.
